Intel S1200V3RP Technical Product Specification

Intel® Server Board S1200V3RP TPS BIOS Setup Interface
Revision 1.2
163
9. ME Firmware Revision
Option Values: <ME FW Rev display>
Help Text: <None>
Comments: Information only.
Back to [System Information Screen] — [Server Management Screen] — [Screen Map]
10. SDR Revision
Option Values: <SDR Rev display>
Help Text: <None>
Comments: Information only.
Back to [System Information Screen] — [Server Management Screen] — [Screen Map]
11. UUID
Option Values: <UUID display>
Help Text: <None>
Comments: Information only.
Back to [System Information Screen] — [Server Management Screen] — [Screen Map]
9.4.2.17 BMC LAN Configuration
To access this screen from the Main screen, select Server Management > BMC LAN
Configuration. To move to another screen, press the <Esc> key to return to the Server
Management screen, then select the desired screen.
The BMC configuration screen allows the user to configure the BMC Baseboard LAN channel
and an Intel
®
RMM4 LAN channel, and to manage BMC User settings for up to five BMC Users.
An Intel
®
RMM4 Management Module may be installed in the server system.
If the Management Module is installed, it may also have a Dedicated Server Management NIC
Module (DMN) installed with it. In that case, the LAN settings for the Intel
®
RMM4 with
Dedicated Server Management NIC may be configured.
When there is no Management Module installed in the system, or there is an Intel
®
RMM4-Lite
without a DMN installed, the LAN settings specific to the Intel
®
RMM4 are grayed out and not
available.
This screen has a choice of IPv4 or IPv6 addressing. When IPv6 is disabled, only the IPv4
addressing options appear. When IPv6 is enabled, the IPv4 options are grayed out and
unavailable, and there is an additional section active for IPv6-addressing. This is true for both
