Intel S1200V3RP Technical Product Specification

Overview Intel® Server Board S1200V3RP TPS
Revision 1.2
4
Feature
Description
3Gbps through six onboard SATA connectors.
RAID Support
 Intel
®
RSTe SW RAID through onboard SATA connectors provides SATA RAID 0/1/10/5.
 Intel
®
Embedded Server RAID Technology II through onboard SATA connectors provides
SATA RAID 0/1/10 and optional RAID 5 support provided by the Intel
®
RAID Activation
Key RKSATA4R5.
 S1200V3RPL, S1200V3RPO, and S1200V3RPM support one optional internal SAS
module connector which supports Intel
®
SAS or ROC modules with the product code of
RMS25CB080, RMS25JB080, RMS25CB040, and RMS25JB040.
External (Back
Panel) I/O
connections
External connections:
 DB9 serial port A connection.
 One DB-15 video connector.
 Two RJ-45 NIC connectors for 10/100/1000 Mb connections through the two Intel
®
Ethernet Controller I210.
 Two USB 3.0 ports at the back of the board.
 Two USB 2.0 ports at the back of the board.
Internal I/O
connectors/ headers
 One 2x10 pin USB 3.0 header, providing front panel support for two USB ports
respectively on S1200V3RPL, S1200V3RPO, and S1200V3RPM.
 One 2x5 pin USB 2.0 headers, providing front panel support for two USB ports
respectively.
 One internal 2x5 pin serial port B header.
 One internal Type-A USB 2.0 port.
 One 9 pin USB header for eUSB SSD.
 One 1x7 pin header for optional Intel
®
Local Control Panel support.
 One combined header consists of a 24-pin SSI-EEB compliant front panel header.
Video Support
 Integrated 2D video controller.
 Dual monitor video mode is supported.
 16 MB DDR3 Memory.
 Only S1200V3RPM supports integrated graphics support for processors with Intel
®
Graphics Technology. The processor graphics contains generation 7.5 graphics core
architecture. This enables substantial gains in performance and lower power consumption
over previous generations. Up to 20 EUs are supported depending on the processor SKU.
The maximum resolution should be 3840x2160@60Hz, 24bpp.
LAN
Two Gigabit Ethernet Ports through the two Intel
®
Ethernet Controller I210 PHYs.
Security
Intel
®
TPM Module AXXTPME5 (Accessory Option).
Server Management
 Integrated Baseboard Management Controller, IPMI 2.0 compliant.
 Support for Intel
®
Remote Management Module 4 solutions (Optional except on
S1200V3RPS).
 Support for Intel
®
Remote Management Module 4 Lite solutions (Optional except on
S1200V3RPS).
 Support for Intel
®
System Management Software.
 Support for Intel
®
Intelligent Power Node Manager (Need PMBus*-compliant power
supply).
Form Factor
microATX 9.6”x9.6” compliant form factor.
Compatible Intel
®
Server Chassis
Intel
®
Server Chassis P4000S for S1200V3RP.
