Rack Mount Kit Install Instructions (optional)
82 Intel® Entry Server Chassis SC5299-E UP/DP/WS/BRP User Guide
4. If installed, remove the chassis feet. Remove pin from rubber foot (see letter “A” in
the following figure). Remove rubber foot from chassis hole (see letter “B”). Repeat
process for remaining feet.
Figure 103. Removing Chassis Feet
5. Remove the top side cover by pressing the latch and pushing back on the side cover to
slide rearward and lift from chassis.
Figure 104. Removing Top Side Cover from Chassis
TP01710
B
A
TP00958
