Intel® Entry Server Chassis SC5299-E UP/DP/WS/BRP User Guide 1
1 Server Chassis Features
This chapter describes the main features of the Intel
®
Entry Server Chassis SC5299-E.
The location of important chassis components and connections, as well as a description of
LED identification, are also presented.
Figure 1. Front View of Intel
®
Entry Server Chassis SC5299-E
The Intel
®
Entry Server Chassis SC5299-E is a 5.2U pedestal
1
server chassis and is
available in four configurations: UP (uni-processor),DP (dual-processor), WS
(workstation), and BRP (base redundant power). The chassis is designed to support the
Intel
®
Server Boards S5000XVN, S5000PSL, S5000XSL, S5000VSA, S3000AH,
S3200SHV, S3210SHLC and S3210SHLX. The type of server board supported is
dependent upon the configuration purchased. See Table 1 for a list of the Intel
®
server
boards that are supported by each server chassis configuration.
AF000307
1. The Intel
®
Entry Server Chassis SC5299-E can be configured as a rack-mountable server chassis when outfitted
with the optional Rack Mount Kit (order code APP3RACKIT).
Table 1. Breakdown of Intel
®
Entry Server Chassis SC5299-E Configurations
Intel
®
Entry Server Chassis
SC5299-E
Configuration
Intel
®
Server Boards Supported
1
UP (Uni-processor) Intel® Server Boards S3200SHV, S3210SHLC and
S3210SHLX
DP (Dual-processor) Intel
®
Server Boards S5000VSA, S5000XSL, S5000PSL and
S3000AH
WS (Workstation) Intel
®
Server Board S5000XVN
BRP (Base Redundant Power) Intel
®
Server Boards S5000VSA, S5000XSL, S5000PSL and
S3000AH
