Server Chassis Features
Intel® Entry Server Chassis SC5299-E UP/DP/WS/BRP User Guide 9
Peripheral Devices
The server chassis provides locations and hardware for installing hard drives, a floppy
drive, a CD-ROM drive, a DVD-ROM drive or a tape drive. The drives must be purchased
separately. The following figure shows the available options.
NOTE: It is recommended that screws be used to secure large devices if shipping chassis
integrated.
Figure 8. Optional Peripheral Devices (DP/WS/BRP configuration shown)
Hard Disk Drives
The server chassis ships with one fixed hard drive cage capable of supporting up to six
cabled 3.5-in x 1-in hard drives. Power requirements for each individual hard drive may
limit the maximum number of drives that can be integrated into the server chassis.
An optional hot-swap SCSI or SAS/SATA backplane hard drive cage (capable of handling
up to six hot-swappable SCSI, SATA or SAS hard drives) may be purchased to replace the
fixed hard drive cage. See Table 3 for order code information.
For instructions on installing hard drives, see “Installing and Removing a Fixed Hard
Drive”.
TP02032
A
