96 Advisor Advanced ATSx000A(-IP) Installation and Programming Manual
When a zone is created, it is given the default name “Zone n”.
Enter this menu to edit the current name.
A zone name can consist of 16 characters.
4.1.n.2 Zone type
Use the Zone type menu to set the zone type for a specific zone. The zone type
determines exactly how the zone functions in given circumstances. Each zone
type behaves differently.
Notes
• Available zone options depend on the zone type.
• Zone type for a wireless device is initially defined by the device type during
the device learning. For example, the zone with a panic button is set by
default with type “Panic”.
All available zone types and their options are listed in “Zone types” (see
page 233).
4.1.n.3 Isolated
The Isolated menu allows you to isolate or de-isolate the selected zone.
4.1.n.4 Zone location
4>Zone location
Panel 1.1
The Zone location field informs what physical input the zone is connected to.
4.1.n.5 Areas
The zone needs an area to be able to send alarm information to the central
station, and to be able to reset when an alarm occurs. Use the Areas menu to
assign the area to the zone that has to alarm when the zone is activated and the
area status (set or unset) meets the requirement for the zone type.
In case multiple areas are selected, the alarm is reported to the lowest area
number assigned. The alarm occurs depending on the zone type and only if all
assigned areas are set.
The function of the zone depends on the zone type selected during
programming.
The screen shows a list of areas that the zone is assigned to. For example, the
screen above shows that the zone is assigned to areas 1 and 2.
