172 Advisor Advanced ATSx000A(-IP) Installation and Programming Manual
Events
9.2 Event options
1>CS mapping
2 Voice mapping
The Event options menu contains event options.
See “Alarm reporting principles” on page 206 for more details on event reporting.
9.2.1 CS mapping
01>AN Report to
>1234..........<
The CS mapping menu allows you to map reporting events to the specific central
stations.
The list of events is shown in “Reporting codes used in Advisor Advanced” on
page 223.
9.2.2 Voice mapping
The Voice mapping menu allows you to assign a particular voice message
(0 to 14) to each system event. 0 means that no message is assigned.
The list of events is shown in the “Reporting codes used in Advisor Advanced” on
page 223.
9.2.3 Delayed events
The Delayed events menu allows you to set a delay for particular events.
The first menu entry, 9.2.3.0 Delay timer, allows you to set the global reporting
delay from 0 to 250 sec.
The next menu entries represent the particular events. If the option is On, the
delay is applied.
For the list of events, see the “Reporting codes used in Advisor Advanced” on
page 223.
