Advisor Advanced ATSx000A(-IP) Installation and Programming Manual 193
User programmable functions
You can program your own user functions that can later be activated
automatically or manually. For example, you can program a user function for
setting an area or switching on an output, and then define a schedule for it.
Programming menu
The function programming menu is accessible from various menus where user
programmable functions are used.
The list of allowed functions may vary for different menus.
To program a user function:
1 Type
>None<
First, choose an appropriate function type using submenu 1.
Next, configure function parameters in submenu 2.
Available parameters depend on the selected function type. For particular types
submenu 2 is disabled.
Note: Particular functions require user code entering. To disable it, switch off the
“User Code Req” parameter, if allowed.
Depending on the activation method, the following function types and parameters
may be available.
Table 37: Available function types and parameters
Type
Description
Available parameters
None
No function is assigned
None
Set
Set areas [1][2]
1. Areas selection
2. User code requirement
Unset
Unset areas [1]
1. Areas selection
Trigger
Change a trigger state
1. Trigger name
2. State change: Clear, Set, or Toggle
Part set 1
Part set 1 for areas [1][2]
1. Areas selection
2. User code requirement
Part set 2
Part set 2 for areas [1][2]
1. Areas selection
2. User code requirement
Inhibit
Inhibit zones [1][3]
None
Test call
Execute a test call [3][4]
None
PC connection
Establish connection with the PC
[1][3]
None
Service in
Allow service in [5]
None
Panic
Activate panic alarm
None
