152 Advisor Advanced ATSx000A(-IP) Installation and Programming Manual
Zones
8.5 Zone options
The Input options menu defines options of zone inputs.
8.5.1 Input mode
The Input mode option determines the configuration of zone inputs in the panel.
The following values can be set:
• Single NO: In the single zone mode the panel can only detect an alarm from
the zone. In the single input mode normal state depends on the EOL value. If
this value is set to “No EOL” in “8.5.2 EOL” below, normal state for Single NO
zone is open.
• Single NC: Similar to Single NO above, but If EOL is disabled in “8.5.2 EOL”
below, normal state for zone is short.
• Dual loop: For dual loop to operate, every zone needs two or three EOL
resistors. This enables the panel to detect multiple zone states, including
alarm, tamper, masking etc., depending on connection type and EOL value
set in “8.5.2 EOL” below. See “Zone connection” on page 15 for more details
on EOL usage.
In the Dual loop mode, open or short input state causes zone tamper.
This is a setting for panel only. For expanders, see “2.2.2.n.4.4 Input mode” on
page 76.
8.5.2 EOL
The menu allows you to define end-of-line resistor values. For different input
modes the following values can be available: 1k0, 1k5, 2k, 2k2, 2k2+4k7, 3k3,
3k74, 4k7, 5k6, 6k8, 8k2, 10k, No EOL.
Note: Available EOL values depend on “8.5.1 Input mode” option above.
See “Zone connection” on page 15 for more details on EOL usage.
This is a setting for panel only. For expanders, see “2.2.2.n.4.5 EOL” on page 76.
