76 Advisor Advanced ATSx000A(-IP) Installation and Programming Manual
2.2.2.n.4 Exp settings
The Expander settings menu contains menus shown below, which are necessary
to configure the selected expander.
Note: The available settings depend on the expander type.
2.2.2.n.4.1 Expander name
1 Expander name
>Expander 1 <
Use the Expander name option to enter a name that identifies the expander to
the end-user.
When an expander is created, it is given the default name “Expander <n>”,
where <n> is the expander address. Enter this menu to edit the current name.
An expander name can consist of 16 characters.
2.2.2.n.4.2 Tamper area
The Tamper area option determines which area receives expander tamper and
fault events. To change it, press Enter and select the area.
2.2.2.n.4.3 Isolate expander
Use the Isolate expander command to isolate the tamper fault events on the
selected expander. The expander however remains functional.
2.2.2.n.4.4 Input mode
The Input mode option determines the configuration of zone inputs in the
expander. This setting is similar to the panel zone input mode, which is described
in “8.5.1 Input mode” on page 152.
See “Zone connection” on page 15 for more details on EOL usage.
2.2.2.n.4.5 EOL
The End of line resistor menu allows you to define an end-of-line resistor value
for expander zone inputs. This setting is similar to the panel zone input EOL,
which is described in “8.5.2 EOL” on page 152.
See “Zone connection” on page 15 for more details on EOL usage.
