4 Advisor Advanced ATSx000A(-IP) Installation and Programming Manual
Advisor Advanced layout
Figure 7: Advisor Advanced ATSx000A(-IP) PCB layout
(1) Interface to output expander
(2) IP communication LED (ATS-IP only)
(3) Ethernet RJ-45 connector (ATS-IP only)
(4) USB fault LED
(5) USB power LED
(7) USB connector (mini-B type)
(8) MI-bus connector for MI devices
(9) Interface to input expander
(12) PSTN line connection and panel earth
terminal
(13) Panel earth terminal
(14) External tamper switch
(15) RS-485 system databus connections
(16) T2: Device firmware upgrade mode
(DFU)
(17) RS-485 system databus communication
LEDs
(18) T1: Restores the codes of master users
(installer and supervisor)
(19) System databus termination jumper
(20) AC power supply connector
(ATS1000A-SM only)
(21) AC power supply terminal
(22) Battery connection
(23) Low current (OC) outputs
(24) High current outputs
(25) Siren tamper switch
(26) 12 VDC auxiliary power output
(27) Zone inputs
(23)
(22)
(21)()20 (24) (25) (26) (27)
()2 ()3 ()4 ()7 (8) (9)
(1 )2
(1 )4
(1)
(1 )9
(1 )7
(1 )5
Rx
Tx
IP
USB
MI
IP
CON12
LK2
CON13
T1
T2
LK3
S3
S4
S5
+
+
S1
C
+
S2
C T C
+
+
- -
1 C 2 3 C 4 5 C 6 7 C 8
~
~
+
-
AC
BATT
LC-OUTPUTS
HC-OUTPUTS
SIR TMP
AUX POWER
INPUTS
Ax/R1
B/TA/R
EARTH
CTD-
D+
0V
+12V
COMMS
TAMPER
PSTN
(1 )8
(1 )6
()5
(13)
