168 Advisor Advanced ATSx000A(-IP) Installation and Programming Manual
PSTN and ISDN specific options
9.1.n.4 Phone
Every central station reports to one telephone number. The phone number can
contain up to 20 digits. The following special characters are available:
• P: Pause (3 s).
• T: Waiting for dial tone.
Note: To enter a character, press the corresponding key twice.
IP and GSM/GPRS specific options
9.1.n.4 Destination/IP
The Destination menu contains the configuration of the reporting receiver.
9.1.n.4.1 Dest name
Every central station reports to one IP address.
A destination name can be a numeric IP address or an alphabetic domain
address. See also “How to edit a host address” on page 39.
9.1.n.4.2 Dest port
The destination port is used to report to the host selected in “9.1.n.4.1 Dest
name” above.
9.1.n.4.3 Ping host
The Ping host command allows you to send a ping to the selected central station.
This command is used to check if the central station is present and accessible
from the panel in the network.
The Tx/Rx value indicates a number of packets sent and received.
Note: Monitoring station can be configured to not respond to ping requests, thus
this feature may not work with every CS IP address. To test the communication
path, use menu “1.2.7.n.2 Ping host” described on page 56 to send ping to
another host.
