106 Advisor Advanced ATSx000A(-IP) Installation and Programming Manual
Table 28: Wireless sensor options
Option
Sensor type
Description
Reed and contact
Door/window sensor
Report alarms from both sources
Contact
Door/window sensor
Ignore reed alarms
Reed and shock
Shock sensor
Report alarms from both sources
Shock sensor
Shock sensor
Ignore reed alarms
Reed
Door/window sensor,
shock sensor
Only report reed alarms
Notice tamper
Smoke sensor
Control housing tamper alarms
Ignore tamper
Smoke sensor
Ignore housing tamper alarms
4.1.n.7.5 Remove RF dev
Remove RF dev?
>Cancel<
Select Ok and press Enter to remove the wireless device from the wireless
expander database.
Copying zones
4.1.n.8 Copy
1>Copy params
>>>
Use Copy menu to copy zone parameters.
The following copy methods are available.
4.1.n.8.1 Copy par. from
Zone 1
Zone 2
Use the menu to import all zone parameters from a particular zone to the
selected one.
Choose the zone which parameters must be copied to the selected one, and
press Enter.
INFO
Params copied
All settings except the name are copied.
4.1.n.8.2 Block assign
Start input
>>>
Use the Block assign menu to copy all selected zone parameters to a range of
inputs, creating the appropriate zones.
