Advisor Advanced ATSx000A(-IP) Installation and Programming Manual 119
6.1.n.2.x Select event
Select the appropriate event to configure it.
To choose an appropriate event, you must define the source of the event first.
The source is defined by a group of objects, and an object within this group.
Available groups are listed in “Advisor Advanced events” on page 215.
When the group and the object (if available) are selected, select the appropriate
event. The available selection depends on the selected source. The full event list
with sources is shown in the “Advisor Advanced events” on page 215.
The following functions are available for the selected event:
Table 30: Event configuration commands
Select an element (or all elements) from the group above
Select an event for the element above
Invert the selected event. If inverted, it is marked with '!' in the formula
Remove the selected event
6.1.n.2.y Select operator
All events are joined with logical operators. Choose the operator to change it.
Valid operators are AND, OR, and XOR.
6.1.n.3 Invert
The Invert option specifies if the condition filter output is inverted.
