Advisor Advanced ATSx000A(-IP) Installation and Programming Manual 47
Notes
• Only existing RF expanders are displayed.
• The function is not supported in wireless expanders ATS1235 with firmware
version older than 1.13.
Enter the physical input number on this location. The RSSI is displayed for the
selected zone.
Note: In case of ATS1235, the value is updated automatically each time the
selected zone is activated.
If the wireless detector is equipped with two wireless transmitters, LDR (Low
Data Rate) and HDR (High Data Rate), the screen above shows LDR data.
Press Right to toggle between LDR and HDR receiver data, or wait 2 seconds for
the screen to scroll automatically.
For more information on the communication quality, refer to the appropriate
wireless expander manual.
1.2.1.4 RF diagnostics
1>Expander 1
2 Expander 5
Select the input location first.
Notes
• Only existing RF expanders are displayed.
• The function is not supported in wireless expanders ATS1235 with firmware
version older than 1.13.
Enter the physical input number on this location. The RF state is then displayed,
for example:
The device can report the following states:
• RF state OK: The RF device is working properly
• No data: No data received from the RF device
• LB: Low battery fault
• SS: Short supervision fault
• LS: Long supervision fault
• D: Fire sensor is contaminated
