52 Advisor Advanced ATSx000A(-IP) Installation and Programming Manual
When all zones are tested successfully, the following message is displayed.
The test is cancelled if the Clear key is pressed. There is also a maximum time
limit on the test, set in “8.1.3.3 Walk test time” (see page 140). The test fails if
this timer expires. If engineer reset fails and inhibit reporting has not been
enabled when accessing the programming mode then a message is sent to the
central station to indicate that the test failed (see “Reporting codes used in
Advisor Advanced” on page 223).
1.2.5.2 Walk test opts
The Options menu allows setting up the following walk test options.
1.2.5.2.1 Use internal siren
If the Use internal siren option is set to Yes, each tested zone activation is
signalled by the internal siren.
1.2.5.2.2 Use buzzers
If set to Yes, each tested zone activation is signalled by keypad buzzers.
1.2.5.2.3 Log untested
If the Log untested option is set to Yes, untested zones are recorded in the
system log.
1.2.5.2.4 Zone tamper
If the Zone tamper option is set to Yes, the zone tamper is included into the walk
test.
1.2.5.2.5 Rkp/Exp tamper
If the Keypad/expander tamper option is set to Yes, the tamper alarms from
keypads and expanders assigned to this area also have to be tested.
