10BChapter 11: Playing back a recording
82 TruVision DVR 11 and DVR 11c User Manual
Figure 25: Playback window
1. Playback viewer.
2. Camera panel. Select the cameras for
playback. Move the mouse over the area to
display the list of cameras available.
3. Calendar panel.
Blue: Current date
Yellow: Recordings available on the DVR.
4. Playback control toolbar. See Figure 26.
The playback control toolbar
It is easy to manually control playback using the playback control toolbar. See
Figure 26 below.
Note: The control toolbar does not appear for instant playback.
Figure 26: Playback control toolbar (search playback example shown)
Ite
m Description
1
. Audio and video control toolbar:
/ Audio on/off.
/ Start/stop a video clip during playback. Sections of a recording can be
saved to an external storage device.
Archive files
2
. Playback control toolbar:
Reverse play the recording. Click again to pause.
Stop playback. Timeline jumps back to 00:00 time (midnight).
Play recording. Click again to pause.
