18 Intermec EasyCoder ESim v4.00—Programmer’s Reference Manual
Chapter 4—Editing in Direct Mode
Example
Assuming that...
• the printer has been set up for the application (see page 14),
• the length of the label and the gap has been determined by printing a
Test Label (see page 2),
• and the graphic used in the example has been downloaded to the
printer as described on page 68 (GM command
1
),
...we will now print two copies of a label which we will edit in the Direct
Mode. The label will look like the example on page 20.
The label can be printed as many times as you want, as long as it still is
stored in the image buffer. Once replaced, it cannot be retrieved. It also
implies that counters and variables cannot be used.
Command Explanation
↵
CR/LF to start command structure
N↵
Clear image memory
X0,0,4,752,584↵
Draw a box
LO0,144,752,4↵
Draw a line
LO440,232,4,160↵
Draw a line
A40,400,1,1,1,1,N,"Made in Sweden"↵
Write a 90° text line of fi xed data
A24,160,0,5,1,1,R,"EASYCODER"↵
Write a text line of fi xed data
A24,250,0,4,1,1,N,"MODEL: 501SA"↵
Write a text line of fi xed data
A472,312,0,4,1,1,N,"Checked by: Dan"↵
Write a text line of fi xed data
A24,312,0,4,1,1,N,"SERIAL#: 000001"↵
Write a text line of fi xed data
B280,440,0,1,2,3,96,B,"S 000001"↵
Write barcode representing fi xed data
GG24,12,"LOGO"↵
Write a graphic from graphics memory
1
P2↵
Print command to image buffer; Print
2 copies
1
/. The Intermec logotype is not included in the software package and
is only included in the example to demonstrate how to print a graphics
fi eld. You can substitute it with any graphics of approximately the same
size. If you fi nd it diffi cult to download graphics, you could omit the GG
command from the example until you have become more familiar with
the concept.
