Intermec EasyCoder ESim v4.00—Programmer’s Reference Manual 31
Chapter 7—Commands
A – Print Text
Description This command is used to print an ASCII text string.
Syntax Ap
1
,p
2
,p
3
,p
4
,p
5
,p
6
,p
7
,"DATA"
Parameters p
1
Horizontal start position (X) in dots.
p
2
Vertical start position (Y) in dots.
p
3
0 No Rotation. Left to right.
1 90 degrees rotation. Left to right
2 180 degrees rotation. Left to right
3 270 degrees rotation. Left to right
4 No Rotation. Top to bottom. Asian fonts (p4=8) only
5 90 degrees rotation. Top to bottom. Asian fonts (p4=8) only
6 180 degrees rotation. Top to bottom. Asian fonts (p4=8) only
7 270 degrees rotation. Top to bottom. Asian fonts (p4=8) only
p
4
Font Selection:
203.2 dpi (8 dots/mm) 300 dpi (11.81 dots/mm)
1 20.3 cpi, 6 points (8 x 12 dots) 25 cpi, 4 points (12 x 20 dots)
2 16.9 cpi, 7 points (10 x 16 dots) 8.75 cpi, 6 points (16 x 28 dots)
3 14.5 cpi, 10 points (12 x 20 dots) 15 cpi, 8 points (20 x 36 dots)
4 12.7 cpi, 12 points (14 x 24 dots) 12.5 cpi, 10 points (24 x 44 dots)
5 5.6 cpi, 24 points (32 x 48 dots) 6.25 cpi, 21 points (48 x 80 dots)
8 Asian fonts :
- Korean Korean.24 (24 x 24 dots in double-byte)
- Chinese GB GB.24 (24 x 24 dots in double-byte)
- Chinese BIG-5 Big5.24 (24 x 24 dots in double-byte)
- Japanese Japanese.24 (24 x 24 dots in double-byte)
- Latin (12 x 24 dots in single-byte,
included in all .24 fonts)
a–z Soft Fonts (dot size controlled by ES com-
mand)
p
5
Horizontal multiplier 1, 2, 3, 4, 6, 8.
p
6
Vertical multiplier 1, 2, 3, 4, 5, 6, 7, 8, 9.
p
7
N Normal image
R Reverse image
"DATA" Represents a fi xed data fi eld.
When using Asian double-byte fonts, specify both bytes as ASCII decimal
values, starting with the fi rst value being larger than ASCII 127 dec (ASCII
7F hex), or below ASCII 127 (ASCII 7F hex) decimal to specify a Latin character.
