Intermec EasyCoder C4 - Print Direction

Intermec EasyCoder C4 – Programmer’s Guide Ed. 3 97
Chapter 7 Commands
Description This command is used to select the print orientation.
Syntax Zp
1
Parameters p
1
Print orientation:
T Start printing from the top of image buffer (default).
B Start printing from the bottom of image buffer.
Remarks This command affects the complete print image, including text, bar codes,
graphics, lines, and boxes, as well as the location of the reference point (see
R command).
Note that printing a test label in the Test Mode, or by means of a U or UP command,
will reset the print direction to default (= ZT).
ZT Command:
ZB Command:
Example ZB ↵ :Starts printing from the bottom of the image buffer
Z – Print Direction
EASYCODER C4
Feed Direction
EASYCODER C4
Feed Direction
