Intermec EasyCoder C4 – Programmer’s Guide Ed. 3 35
Chapter 7 Commands
b – PDF417
Description The following PDF 417 bar code specifi c options should append the general part of
the two-dimensional code command (see b command, general part).
Syntax [www,hhh,s,c,p,f,d,x,y,r,I,t,o],"DATA"
Parameters www Maximum print width in dots (3 digits).
hhh Maximum print height in dots (3 digits).
s Sets error correction level. Legal values are 0 thru 8.
If level is not specifi ed, a level that will generate about 1/8 as many ECC code
words as data code words is selected.
c Selects data compression method:
0 Selects auto-encoding (default).
1 Selects binary mode.
p Print human readable code appended by additional variables:
xxx horizontal start location (3 digits).
yyy vertical start location (3 digits).
mmm maximum characters per line (3 digits).
f Center pattern in area:
0 The pattern will print upper left justifi ed in the area defi ned by the w
and h values.
1 The pattern is printed in middle of the area defi ned by the w and h
values (default).
d- Print code words:
0 Values of code words not printed (default).
1 Values of code words printed.
x- Module width. Legal values are 2-9.
y- Set bar height. Legal values are 4-99 dots high.
r- Maximum row count (refer to PDF 417 specifi cations).
l- Maximum column count (refer to PDF 417 specifi cations).
Note that this character is lowercase L.
t- Truncated fl ag:
0 Not truncated.
1 Truncated.
o- Rotation:
0 0° rotation clockwise.
1 90° rotation clockwise.
2 180° rotation clockwise.
3 270° rotation clockwise.
DATA Represents a fi xed data fi eld.
