Intermec EasyCoder C4 - Two-Dimensional Bar Codes, General Part

Intermec EasyCoder C4 – Programmer’s Guide Ed. 3 33
Chapter 7 Commands
Description This command is used to print two of three complex bar codes; Datamatrix, PDF
417, and MaxiCode. The command consists of two parts; a leading set of general
positioning and bar type select parameters, and a trailing code-specifi c part defi ning
the bar code’s appearance and its input data.
Syntax bp
1
,p
2
,p
3
,[code specifi c options]
Parameters p
1
Horizontal start position (X) in dots.
p
2
Vertical start position (Y) in dots.
p
3
Code type:
D Selects Datamatrix (option).
M Selects MaxiCode.
P Selects PDF417.
[code specifi c options], see the following two pages.
Remarks The standard program packages contains MaxiCode and PDF 417, whereas the
optional program package contains Datamatrix and MaxiCode.
If the amount of data will not fi t in the area specifi ed, the indicator will light
orange, indicating an error.
b – Two-Dimensional Bar Codes, General Part
