Intermec EasyCoder PF4i User Manual

Printing
PrintTechnique DirectThermalandThermalTrans
PrintheadResolution 8dots/mm(203.2dpi) Option300dp
PrintSpeed(variable
)
100to200mm/sec.( ≈
4to8in./sec.)
8dots/mm
300dpi
PrintWidth(max) 104mm(4.095inches)
105.7mm(4.161inches)
8dots/mm
300dpi
PrintLength(max)
1
32767dots=409.5cm(161.25in.)
MediaWidth(min/max) 25to114.3mm(1to4.5inches) Standardedg
e
MediaWidth(min/max) 40/80to114.3mm(1.57/3.15to4.
5
Quick-Load
guides
MediaRollDiameter
(max)
152mm(6.00inches)
213mm(8.38inches)
Longsidedoo
r
MediaRollCoreDiamet
er
38to40mm(1.5inches)or76mm
(3inches)
RibbonWidth(min/max 25to110mm(1to4.33inches)
RibbonRollDiameter
(outer)
65mm(2.56inches)equivalentto
240-300m(787-985ft)ofribbon
Dependingon
ribbonthick
ness
RibbonRollCoreDia-
meter(inner)
25.4mm(1.00inches)
PrintDirections 4
Modes of Operation
Tear-Off(Straight-
through)
Yes
Cut-Off Optional Withcutter
Peel-Off(Self-strip
)
Optional Withliner
takeupunit
Firmware
OperatingSystem IntermecFingerprintv8.20 Incl.Direct
Protocol
SmoothFonts TrueDocandTrueTypefonts
Built-inscaleablefo
nts
15
2
Unicodefont
s
Built-inbarcodesymb
olo-
53
StartupProgram(std) IntermecShellv8.1
Industrial
—
User
’
s
Guide
(Fingerprint)

Intermec EasyCoder PF4i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power consumption (standby)	15 W
Power consumption (printing)	300 W
Media thickness	3/7.5 mm
Maximum label width	104 mm
Maximum label length	0.4 m
Maximum roll diameter	152.4 /213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Product color	Blue, Silver
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	405 mm
Width	244 mm
Height	178 mm
Weight	8000 g
