Intermec EasyCoder PF4i User Manual

Physical Measures
Dimensions(WxLxH) 244x405x178mm(9.61x15.93x
7.00inches)
253x447x178mm(9.96x17.60x
7.00inches)
244x475x225mm(9.61x18.70x
8.86inches
Withlongsid
e
door
Withpaper
cutter
With8-in.
Weight(excludingmed 7to8kg(15.5to17.7pounds)
AmbientOperatingTem
-
+5°Cto+40°C(+41°Fto+104°
F)
Humidity 20to80%non-condensing
Electronics
Microprocessor 32bitRISC
On-boardFlashSIMMs 2socketsfor4MBor8MBeach Std.1x4MB
On-boardSDRAMSIMM 1socketfor8MBor16MB Std.8MB
Power Supply
ACVoltage 90to265VAC,45to65Hz
PFCRegulation IEC61000-3-2
PowerConsumption Standby15W;Peak300W
Sensors
LabelGap/BlackMark/
OutofMedia
Yes 5 fi
xedposition
PrintheadLifted Yes
RibbonEnd/RibbonLow Yes
Controls
ControlLamps 3
Display 2x16characterLCD Background
light
Keyboard 22keysmembrane-switchtype
Printbutton 1
Beeper Yes
Data Interfaces
Serial 1xRS-232+1xUSB
BarCodeWand Yes
Appendix
A
—
Technical
Data
Intermec
EasyCoder
PF4i
Compact
Industrial
—
User
’
s
Guide
(Fingerprint)

Intermec EasyCoder PF4i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power consumption (standby)	15 W
Power consumption (printing)	300 W
Media thickness	3/7.5 mm
Maximum label width	104 mm
Maximum label length	0.4 m
Maximum roll diameter	152.4 /213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Product color	Blue, Silver
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	405 mm
Width	244 mm
Height	178 mm
Weight	8000 g
