Goodrive200 inverters Basic operation instruction
145
Function
code
Name
Detailed instruction of parameters Default
value
receiving the stop command
LED thousands: ∧/∨ keys and digital
potentiometer Integral function
0:The Integral function is effective
1:The Integral function is ineffective
P08.43
K
eypad data potentiometer
integral ratio
0.01~10.00s 0.10s
P08.44
UP/DOWN terminals
control
0x00~0x221
LED ones: frequency control
selection
0:UP/DOWN terminals setting effective
1:UP/DOWN terminals setting ineffective
LED tens: frequency control
selection
0:Only effective when P00.06=0 or
P00.07=0
1:All frequency means are effective
2:When the multi-step are priority, it is
ineffective to the multi-step
LED hundreds: action selection when
stop
0:Setting effective
1:Effective in the running, clear after stop
2:Efective in the running, clear after
receiving the stop commands
0x000
P08.45
UP terminals frequency
increasing integral ratio
0.01~50.00Hz/s 0.50s
P08.46
DOWN terminals
frequency integral ratio
0.01~50.00 Hz/s 0.50s
P17.00
Set frequency
0.00Hz~P00.03 (the Max. output
frequency)
0.00Hz
P17.02
Ramp reference frequency
0.00Hz~P00.03 (the Max. output 0.00Hz
