INVT Goodrive270 Series User Manual

Goodrive270 series VFD for fan and pump Basic operation guidelines
-99-
Function
code
Name
Description
Default
potentiometer can be used for the
control.
Tens place: Frequency control selection
0: Valid only when P00.06=0 or P00.07=0
1: Valid for all frequency setting methods
2: Invalid for multi-step speed running
when multi-step speed running has the
priority
LED hundreds place: Action selection for
stop
0: Setting is valid.
1: Valid during running, cleared after stop
2: Valid during running, cleared after a
stop command is received
LED thousands place: Indicates whether
to enable the integral function through
the ∧/∨ key and digital potentiometer.
0: Disable the integral function
1: Enable the integral function
P08.43
Keypad digital potentiometer
integral rate
0.01–10.00s
0.10s
P08.44
UP/DOWN terminal control
setting
0x000–0x221
Ones place: Frequency setting selection
0: The setting made through UP/DOWN
is valid.
1: The setting made through UP/DOWN
is invalid.
Tens place: Frequency control selection
0: Valid only when P00.06=0 or P00.07=0
1: Valid for all frequency setting methods
2: Invalid for multi-step speed running
when multi-step speed running has the
priority
Hundreds place: Action selection for stop
0: Setting is valid.
1: Valid during running, cleared after stop
2: Valid during running, cleared after a
stop command is received
0x000
