INVT Goodrive270 Series - Page 108

Goodrive270 series VFD for fan and pump Basic operation guidelines
-98-
Function
code
Name
Description
Default
6: Multi-step speed running
7: PID control
8: Modbus communication
9: PROFIBUS/CANopen communication
10: Ethernet communication
11: Reserved
12: Reserved
13: PROFINET communication
14–17: Reserved
18: Keypad (for small power models)
P00.08
Reference object of B
frequency command
0: Max. output frequency
1: A frequency command
0
P00.09
Combination mode of
setting source
0: A
1: B
2: (A+B)
3: (A-B)
4: Max(A, B)
5: Min(A, B)
0
P05.01–P
05.06
Function selection of
multifunction digital input
terminals (S1–S4, and
HDIA)
10: Increase frequency setting (UP)
11: Decrease frequency setting (DOWN)
12: Clear the frequency
increase/decrease setting
13: Switch between A setting and B
setting
14: Switch between combination setting
and A setting
15: Switch between combination setting
and B setting
P08.42
Keypad digital control
setting
0x0000–0x1223
LED ones place:
0: Both the ∧ / ∨ key and digital
potentiometer can be used for the
control.
1: Only the ∧/∨ key can be used for
the control.
2: Only the digital potentiometer can be
used for the control.
3: Neither the ∧/∨ key nor the digital
0x0000
