INVT Goodrive270 Series User Manual

Goodrive270 series VFD for fan and pump Basic operation guidelines
-87-
Ready
P00.01=0 (controlled by
keypad)
Motor type
(P02.00)
P02.00=1 P02.00=0
Input motor nameplate
(P02.15–P02.19)
Input motor nameplate
(P02.01–P02.05)
Complete parameter
rotary autotuning
Partial parameter rotary
autotuning
Set autotuning mode
Press "RUN" to start autotuning
Autotuning completed
Autotuning
Synchronous
motor
Asynchronous
motor
Complete parameter
static autotuning
Note:
 Motor parameters must be set correctly according to the motor nameplate.
 If rotary autotuning is selected during motor autotuning, disconnect the motor from the load to put
the motor in static and no-load state. Otherwise, the motor parameter autotuning results may be
incorrect. In addition, autotune P02.06–P02.10 for AMs and autotune P02.20–P02.23 for SMs.
 If static autotuning is selected for motor autotuning, there is no need to disconnect the motor from
the load, but the control performance may be impacted as only a part of the motor parameters
have been autotuned. In addition, autotune P02.06–P02.10 for AMs and autotune
P02.20–P02.22 for SMs. P02.23 can be obtained through calculation.
