Goodrive300-21 integrated machine for air compressor Optional parts
-99-
192mm
138mm
Operation panel
Touch
screen
Cut-out
dimensions
Operation
panel
Step 2 Insert the metal snap-fits into the back, top and bottom mounting jacks of the touch screen,
insert the fastening screws (attached), and then tighten the screws with the cross screwdriver.
Back
Top
Front
Bottom
