INVT Goodrive300-21 Series User Manual

Goodrive300-21 integrated machine for air compressor Function description
-34-
Function
code
Name
Description
Default
Modify
12: Ready for running
13: Pre-exciting
14–19: Reserved
20: External fault is valid
21–22: Reserved
23: Modbus communication virtual terminal
output
24–25: Reserved
26: Special for oil pump (for blower)
27: Auxiliary motor start/stop control (for air
compressor)
28: Solenoid valve control output (for air
compressor)
29: Cooling fan control of main motor (for air
compressor)
30: Reserved
P06.05
Output terminal
polarity selection
The function code is used to set the polarity of
output terminals.
When a bit is 0, the input terminal is positive;
when a bit is 1, the input terminal is negative.
BIT3
BIT2
BIT1
BIT0
TAC2
TAC1
Reser
ved
Y
Setting range: 0–0xF
0
○
P06.06
Y switch-on delay
0.000–50.000s
0.000s
○
P06.07
Y switch-off delay
0.000–50.000s
0.000s
○
P06.08
Reserved
0.000–50.000s
0.000s
○
P06.09
Reserved
0.000–50.000s
0.000s
○
P06.10
TAC1 switch-on
delay
0.000–50.000s
0.000s
○
P06.11
TAC1 switch-off
delay
0.000–50.000s
0.000s
○
P06.12
TAC2 switch-on
delay
0.000–50.000s
0.000s
○
P06.13
TAC2 switch-off
delay
0.000–50.000s
0.000s
○
