INVT Goodrive300-21 Series User Manual

Goodrive300-21 integrated machine for air compressor Function description
-47-
Function
code
Name
Description
Default
Modify
P17.07
Exciting current
-3000.0–3000.0A
0.0A
●
P17.08
Motor power
-300.0% –300.0% (of the motor rated power)
0.0%
●
P17.09
Output torque
-250.0–250.0%
0.0%
●
P17.10
Estimated motor
frequency
0.00–P00.03
0.00Hz
●
P17.11
DC bus voltage
0.0–2000.0V
0V
●
P17.12
Digital input terminal
status
0000–00FF
0
●
P17.13
Digital output
terminal status
0000–000F
0
●
P17.16
Master fault code
0–45 (See P07.27–P07.32 for details)
0
●
P17.17
Fan fault code
0–38 (See P07.27–P07.32 for details)
0
●
P17.19
P1–input voltage
Displays analog input voltage value of
P1-channel. 2.00V–10.00V corresponds to 4–
50mA. P05.32-P05.34 corresponds to
pressure 0.0-P18.04. When P1-input voltage
is detected to be above 9.8V or below 1V, it is
deemed as pressure signal fault.
Range: 0.00–10.00V
0.00V
●
P17.20
PT1 input voltage
Displays the analog input voltage value of PT1
channel. Connect PT100 thermal resistor
temperature sensor in air compressor mode,
and different resistance value will be
generated under different temperature
Different resistance value corresponds to
different input voltage. Therefore, the input
voltage value can correspond to the
corresponding detection temperature. The
input voltage P18.28-P18.29 corresponds to
-20°C-150°C.
Range: 0.00–10.00V
0.00V
●
P17.21
P2–input voltage
Displays analog input voltage value of
P2-channel. 2.00V–10.00V corresponds to 4–
50mA. P05.42-P05.44 corresponds to
pressure 0.0-P18.38. When P2-input voltage
is detected to be above 9.8V or below 1V, it is
deemed as pressure signal fault.
Range: 0.00–10.00V
0.00V
●
