INVT Goodrive300-21 Series User Manual

Goodrive300-21 integrated machine for air compressor Function description
-48-
Function
code
Name
Description
Default
Modify
P17.22
PT2 input voltage
Displays the analog input voltage value of PT2
channel. Connect PT100 thermal resistor
temperature sensor in air compressor mode,
and different resistance value will be
generated under different temperature.
Different resistance value corresponds to
different input voltage. Therefore, the input
voltage value can correspond to the
corresponding detection temperature. The
input voltage P18.32-P18.33 corresponds to
-20°C-150°C.
Range: 0.00–10.00V
0.00V
●
P17.23
PID reference value
Displays the set value of exhaust pressure
signal. 100.0% corresponds to the upper limit
value of exhaust pressure sensor P18.04 (If
P18.37=1, 100% corresponds to P18.38).
Range: -100.0–100.0%
0.0%
●
P17.24
PID feedback value
Displays detection value of exhaust pressure
signal.
Range: -100.0–100.0%
0.0%
●
P17.25
Motor power factor
-1.00–1.00
0.0
●
P17.26
Duration of this run
0–65535m
0m
●
P17.28
ASR controller
output
-300.0%–300.0% (of the motor rated current)
0.0%
●
P17.29
Magnetic pole angle
of SM
0.0–360.0
0.0
●
P17.30
Phase
compensation of SM
-180.0–180.0
0.0
●
P17.36
Output torque
-3000.0Nm–3000.0Nm
0.0Nm
●
P17.38
PID output
Displays PID control adjustment output value
of exhaust pressure signal. 100.0%
corresponds to maximum output frequency
P00.03.
Setting range: -100.00–100.00%
0.00%
●
P18.00
Air compressor
control mode
0: Disable
1: Air compressor control mode
Note: When P18.00=1, P19 group air
compressor state check group is valid.
0
◎
