INVT Goodrive300-21 Series User Manual

Goodrive300-21 integrated machine for air compressor Function description
-68-
Function
code
Name
Description
Default
P09.06
Differential time
(Td)
Used to determine the strength of the change
ratio adjustment on the deviation of PID feedback
and reference from the PID regulator. If feedback
quantity changes 100% during this time period,
the range within which the differential regulator
(ignoring integral function and differential
function) can regulate is the max. frequency
(P00.03).
Longer differential time indicates stronger
adjustment.
0.00–10.00s
1.00s
P09.07
Sampling cycle (T)
0.000–10.000s
0.100s
P09.08
PID control
deviation limit
The feedback value of the PID system is relative
to the max. deviation of the closed loop reference.
The PID regulator stops regulating in the range of
deviation limit. Set the function parameter
properly to adjust the accuracy and stability of the
PID system.
0.0–100.0%
0.1%
P09.09
PID output upper
limit
P09.10–100.0% (Max. frequency or voltage)
100.0%
P09.10
PID output lower
limit
-100.0%–P09.09 (Max. frequency or voltage)
0.0%
P09.11
Feedback offline
detection value
0.0–100.0%
0.0%
P09.12
Feedback offline
detection time
0.0–3600.0s
1.0s
P09.13
PID control
selection
0x0000–0x1111
Ones place:
0: Continue integral control after the frequency
reaches upper/lower limit
1: Stop integral control after the frequency
reaches upper/lower limit
Tens place:
0: Same as the main reference direction
1: Contrary to the main reference direction
Hundreds place:
0x0001
