Ioline FlexJet - Figure 8. Workflow: Output Direct from CAD Software (Without Flexplot)

23
Chapter 1: Overview
Figure 9. Workow using FlexPlot for le conversion and output.
Figure 8. Workow: output direct from CAD software (without FlexPlot).
FlexJet
FlexJet
CAD
Software
FlexPlot
[Network]
HPGL
DM/PL
DXF
ASTM 6959
STD
CAD
Software
HPGL
DM/PL
(Alternate Conguration)
CAD
Software
+
FlexPlot
2. Use FlexPlot software to convert les before sending them
to the FlexJet for output.
The FlexJet includes the FlexPlot software which will convert
many different les into a format that is compatible with the
FlexJet. It also provides an advanced marker queue manage-
ment system and other tools to optimize the performance of the
printer.
