Chapter 5
Parts & Drawings
FlexJet BOM (Bill of Materials)
Part
Number
Description SEQN QTY
107758 SERVICE STATION ASSY, FJ 1 1
107215 PINCHWHEEL ASSY, 6 LB, 1:1, PLASTIC 2 8
108495 KEYPAD ASSY, FJ 3 1
108270 CARRIAGE ASSY, FJ, FRAME-UP 4 1
108227 ASSY, Y TRANS, GT 5 1
107588 TOP BAR ASSY, 600/28AE 6 1
107700 SUPPORT ASSY, TOP BAR, LEFT 7 1
107701 SUPPORT ASSY, TOP BAR, RIGHT 8 1
107590 SHAFT, TOP BAR, 600/28AE 9 1
107698 SPACER, C-SHAPE, 10 OD, .25ID 10 1
106708 TENSIONER ASSY, SC98 11 1
107699 DRIVE SHAFT ASSY, INK-JET 12 1
106684 LEVER ASSY, PINCHWHEEL, REAR 13 1
108225 Y BELT ASSY, GT, 3MM PITCH 14 1
107830 COVER ASSY, BOTTOM, LEFT 15 1
107833 COVER ASSY, BOTTOM, RIGHT 16 1
108305 TAKE-UP ASSY, RIGHT, FJ 17 1
107697 PLATEN, FLEX JET 18 1
107828 TRAVERSE, FLEXJET 19 1
108264 DUST COVER, FJ 20 1
108201 SPACER, DRIVESHAFT, PL, 8.6LG 21 1
108202 SPACER, DRIVESHAFT, PL, 9.3LG 22 1
107774 PLATE, END, RIGHT, FJ 23 1
107775 PLATE, END, LEFT, FJ 24 1
107886 BRACKET, POWER SUPPLY, 5X9 25 1
108252 CHANNEL, TOP, RIGHT, FRONT 26 2
108251 CHANNEL, TOP, LEFT, FRONT 27 2
108349 COVER, LOGIC BOARD, FJ 28 1
106845 SHAFT, CAM, I/S 600 31 1
106550 BELT, .080 X 1/4 X 100T 32 1
100279 CONN, CABLE CLIP 33 10
103026 CONN, CABLE CLIP, .18 DIA 34 3
