Ioline FlexJet Service Manual
Part
Number
Description SEQN QTY
103027 TYRAP, .1 IN X 5 3/4 LG 35 30
106816 MOTOR, SERVO, 24V 36 1
103740 TAPE, FOAM, .5 IN, .025 THICK 37 1
100705 PAD, PEN CAP, 1/4 DIA 38 6
106649 LABEL, DRIVE AREA 39 12
106652 RIVET, PLASTIC, .2 GR X .169 OD 40 8
106693 BUSHING, NYLON,.52ID, .62OD, .75FL 41 2
105933 PULLEY, 16T X .080 X 1/4 43 1
104180 SCREW, #8, .50 LG, SLF TAP, PHP, SE 45 18
105514 SCREW 1/4-20, 1.75 LG, BTM HD SOCK 48 2
104590 SCREW #8, .50 LG, ST, FHP 49 10
102726 SETSCREW #10-32, .75 LG, STEEL 50 15
104013 NUT, #8-32, KEP 51 10
107211 COTTER PIN, 1/8 X .75 53 2
102281 SCREW #10-32, 1.0 LG, PHP 54 1
107850 CABLE ASSY, MOTOR, X, IJ02 55 1
107852 CABLE ASSY, MOTOR, Y, IJ02 56 1
107853 CABLE ASSY, ENCODER, LONG, IJ02 57 2
107854 CABLE ASSY, MTR/ENC, TU, IJ02 58 1
107856 CABLE ASSY, MOTOR, SS, IJ02 59 1
107857 CABLE ASSY, ENCODER, SS, IJ02 60 1
107859 CABLE ASSY, TU SENSOR, IJ02 62 1
108328 PROC, INST, FJ PCB ASSYS 63 1
107861 CABLE ASSY, FAN, SHORT, IJ02 64 1
107862 CABLE ASSY, FAN, LONG, IJ02 65 1
107864 CABLE ASSY, POWER, DC, IJ02 66 1
106951 SPRING, TORSION, .53 ID, .045 WIRE 67 1
108496 POWER SUPPLY, CALIBRATED, 30V 69 1
108177 FAN ASSY, 24-48 V, W/CONN 70 2
104717 NUT, #10-32, HEX, NYLOCK 71 8
108192 POWER ENTRY ASSY, AC, FJ 72 1
107849 CAP, VINYL, .437”D X 1.5”L 73 1
108350 RAMP, STATION, FJ 74 1
108242 MAGNET, NEO, .5 OD, .375 LG 75 1
108074 COVER, WIRE, FJ 78 1
106750 CAP, VINYL, .093 ID, BLK 79 2
103260 SCREW #4-40, .75 LG, PHP 80 4
108314 FERRITE, MOTOR ENCODER, FLEXJET 82 4
105930 LABEL, WARNING, CRUSH HAZARD 83 1
108316 FERRITE, MOTOR POWER, FLEXJET 84 4
107502 WSHR, .500 OD, .145 ID,.031 T, PTFE 85 2
106532 NUT, #6-32, HEX, NYLOCK 86 2
100020 SCREW #6-32, .187 LG, PHP 87 4
100046 SCREW #8-32, 1.25 LG, SHC, FULL THD 88 2
107738 SENSOR, OPTICAL 90 2
