iPECS UCM
Installation Manual Issue 1.1
23
2.3 System Characteristics
This chapter shows the characteristics of iPECS-UCM.
2.3.1 Maximum Capacity
Table 2-3 Maximum Capacity
Server Type Max. Capacity Max. Trunk Port Max Extension Port
UCM-S60K 60,000 30,000 60,000
UCM-S30K 30,000 10,000 30,000
UCM-S10K 10,000 5,000 10,000
UCM-S4K 4,000 2,000 4,000
UCM-S2K 2,000 1,000 2,000
* The total sum ports of Trunk and Extension can’t exceed the Maximum Capacity.
2.3.2 Dimension and Weight
Table 2-4 Dimension and Weight
Item W (mm) L (mm) H (mm) Weight (kg)
UCM-MGC3 443 409.3 310.3 17.3
UCM-1URMC 440 361.8 43.4 5.5
Gateway Module 255 334.5 30 *-
UCM-PSUD 140 334.7 59.7 0.85
* Each Gateway Module has a different weight.
2.3.3 Environment Specifications
Table 2-5 Environmental Specifications
Environment Condition
Temperature
Operation 0~40℃
Storage 0~70℃
Humidity
Operation 20~80% non-condensing
Storage 10~95% non-condensing
