iPECS UCM
Installation Manual Issue 1.1
25
3 General Installation Procedure
The basic steps to install an iPECS UCM are;
1) Locate the area for installing the system
2) Unpacking
3) Install the cabinets
4) Grounding
5) Power connection
6) Install the Gateway Modules in the cabinet
7) Wire the Gateway Modules to the appropriate termination points
8) Wire and connect terminals
9) Initial power-up to default the database
10) Configure the system referring to iPECS UCM F&O manual and WMS manual.
11) Verify the installation.
3.1 Installation and Safety Precautions
Please read the following guidelines concerning installation and wiring before installing the iPECS UCM
System. Also, be sure to comply with applicable local regulations.
When installing the telephone wiring, basic safety precautions always should follow to reduce the risk of fire,
electric shock, and personal injury, including the following:
Do not install the telephone wiring during a lightning storm.
Do not install the telephone jack in wet locations unless the jack specifically is designed for wet
locations.
Do not touch un-insulated telephone wires or terminals unless the telephone line has been
disconnected at the network interface.
Use caution when installing or modifying telephone lines.
Anti-static precautions should be taken during installation.
The iPECS UCM System is designed for floor standing or 19” rack mounting.
Avoid installing in the following places:
In direct sunlight and extremely hot, cold, or humid places (optimal temperature range = 0
o
to 40
o
C).
Places where shocks or vibrations are frequent or strong.
Dusty places or places where the System may encounter water or oil.
Near high frequency generating devices such as sewing machines or electric welding machines.
On or near computers, fax machines, or other office equipment, as well as microwave ovens or air
conditioners.
