3.3.1.5.2 Rectifier Installation Requirements
 Rated voltage: -48V
Rectifier output characteristics
 Rated current: Depends on capacity
 Voltage range: - 46 ~ -54V
 Ripple & Noise: rms 2mV and less (Voice Band, 200 Hz ~ 4 KHz), rms 50mV and less (Other Band)
 Input voltage stability (at full load): ± 5% and less
 Output load stability (10 %~ 100 % Load): 5% and less
To prevent voltage drop, keep wiring as short as possible using cables of sufficient capacity.
Wiring
