iPECS UCM
Installation Manual Issue 1.1
42
3.3.1.5.4 Rectifier Cable Connection
When PSUD is used for the UCM-MGC3, a rectifier is used to feed DC -48V power. Power and ground cable
connected from the rectifier to the system should have the same size and length. Figure 3-16 shows rectifier
and UCM-MGC3 cable connection.
Rectifier cable connection diagram
Figure 3-17 Rectifier Cable Connection Diagram
