iPECS UCM
Installation Manual Issue 1.1
57
Description Pin No Pin No Description
Port 1 TIP 1 33 Port 1 RING
Port 2 TIP 2 34 Port 2 RING
Port 3 TIP 3 35 Port 3 RING
Port 4 TIP 4 36 Port 4 RING
Port 5 TIP 5 37 Port 5 RING
Port 6 TIP 6 38 Port 6 RING
Port 7 TIP 7 39 Port 7 RING
Port 8 TIP 8 40 Port 8 RING
Port 9 TIP 9 41 Port 9 RING
Port 10 TIP 10 42 Port 10 RING
Port 11 TIP 11 43 Port 11 RING
Port 12 TIP 12 44 Port 12 RING
Port 13 TIP 13 45 Port 13 RING
Port 14 TIP 14 46 Port 14 RING
Port 15 TIP 15 47 Port 15 RING
Port 16 TIP 16 48 Port 16 RING
Port 17 TIP 17 49 Port 17 RING
Port 18 TIP 18 50 Port 18 RING
Port 19 TIP 19 51 Port 19 RING
Port 20 TIP 20 52 Port 20 RING
Port 21 TIP 21 53 Port 21 RING
Port 22 TIP 22 54 Port 22 RING
Port 23 TIP 23 55 Port 23 RING
Port 24 TIP 24 56 Port 24 RING
Port 25 TIP 25 57 Port 25 RING
Port 26 TIP 26 58 Port 26 RING
Port 27 TIP 27 59 Port 27 RING
Port 28 TIP 28 60 Port 28 RING
Port 29 TIP 29 61 Port 29 RING
Port 30 TIP 30 62 Port 30 RING
Port 31 TIP 31 63 Port 31 RING
Port 32 TIP 32 64 Port 32 RING
Champ connector wiring (UCM-ASLM)
