4230 Flow Meter
Section 2 Programming
2-23
If you select any of these outputs, the flow meter will request
that you turn them on or off. If you are running on battery and do
not need these options, select OFF. Otherwise, select ON. After
the OPTIONAL OUTPUTS menus have been set, press Enter.
The display will return to the SETUP menu.
The alarm box, also called the High-Low Alarm Box, is an Isco
product that allows you to operate control relays to signal alarms
when flow rate rises above or falls below a certain set value. You
can set both the high and low alarm values from 1 to 99% of the
controlling condition. (See Section 4 for more information about
the alarm box.)
Return to the SETUP menu.
This time, select REPORT SETUP.
This step lets you determine the contents of the reports gen-
erated by the flow meter. The flow meter's report generator is
capable of creating two different reports (A and B) that can be
identical or quite different.
The reason for two reports is to allow the summary of flow meter
recording over different time periods. For example, you might
generate report A weekly, and report B monthly. At this point we
are only interested in selecting the items the flow meter will
include in each report.
Press Enter and the following will appear:
FLOW METER HISTORY is just off the screen, to the right. If
you select FLOW, the following will appear:
Select YES if you want LEVEL to appear in the report.
Select YES if you want FLOW RATE to appear in the report.
Then:
Select YES if you want RAINFALL to appear in the report. You
must have a rain gauge connected to the flow meter to sense
rainfall occurrence. The following will appear:
FLOW METER HISTORY is just off the screen.
This time select DO/PH. The following will appear:
REPORT SETUP
• REPORT A • • REPORT B •
REPORT SETUP
• FLOW • • DO/PH • • YSI 600 • • SAMPLE HISTORY •
LEVEL IN REPORT
• YES • • NO •
FLOW RATE IN REPORT
• YES • • NO •
RAINFALL IN REPORT
• YES • • NO •
REPORT SETUP
• FLOW • • DO/PH • • SAMPLE HISTORY • • FLOW MET...
PH OR DO IN REPORT
• YES • • NO •
