VT50 – Operation
The following buttons can be used to change between the various formats of the
input dialogue for numerical values:
Change to scroll wheel setting.
Change to slider setting.
Change to number block setting.
Proceed as follows to enter a numerical value:
1. From the operating mask select the parameter whose value has to be
changed. Press on the parameter on the touchscreen or turn the scroll wheel
until the parameter is highlighted in white and then press on the scroll wheel.
Once the parameter is highlighted you can, alternatively, also press the "OK"
button.
The input dialogue is opened.
2. Enter the new value. The input method depends on the format of the input
dialogue:
Number
Block
Enter the value using the buttons in the input dialogue or
by turning the scroll wheel.
Scroll wheel
(
Comfort)
Enter the value by turning the scroll wheel.
Slider
Drag the slider or press the + and - buttons until the
desired value is set.
Alternatively, you can enter the value by turning the
scroll wheel.
3. Confirm your input with "OK" or by pressing the scroll wheel.
Note
The terminal takes note of the last format to be selected. The next time the input
dialog for numerical values is requested this format is immediately selected.
Note
The input field is highlighted in red if a value is entered outside the valid value
range. In this case enter another value.
21
