Terminal connection capacity (residual current or temperature measurement inputs and digital inputs / outputs)
Rigid/flexible 0.14 - 1.5mm
2
, AWG 28-16
Flexible with core end sheath without plastic sleeve 0.20 - 1.5mm
2
Flexible with core end sheath with plastic sleeve 0.20 - 1.5mm
2
Tightening torque 0.20 - 0.25Nm
Stripping length 7mm
Terminal connection capacity: serial interface
Single core, multi-core, fine-stranded 0.20 - 1.5mm
2
Terminal pins, core end sheath 0.20 - 1.5mm
2
Tightening torque 0.20 - 0.25Nm
Stripping length 7mm
Terminal connection capacity (voltage and current measurement)
Conductors to be connected. Only one conductor can be connected per terminal!
Current Voltage
Single core, multi-core, fine-stranded 0.2 - 2.5mm
2
, AWG 26-12 0.08 - 4.0mm
2
, AWG 28-12
Terminal pins, core end sheath 0.2 - 2.5mm
2
0.2 - 2.5mm
2
Tightening torque 0.4 - 0.5Nm 0.4 - 0.5Nm
Stripping length 7mm 7mm
