Energy meter
The UMG 96RM-E has power meters for active energy,
reactive energy and apparent energy.
Active energy reading
Total active energy
The active energy
given in this example
is 12 345 678 kWh
The active energy
given in this example
is 134 178 kWh
Reset energy meter (Addr. 507)
The real, apparent and reactive energy meters can only
be reset simultaneously.
Set "001" for address 507 to reset the energy meter.
If you reset the energy meter, the data will
be lost.
To avoid data loss, you should read
and save the measured values before
deletion using the GridVis software.
C
C
Prior to commissioning potential
production dependant contents of the
energy counter, min/max values and
records have to be deleted.
