Recordings
2 recordings are preconfigured in the default factory
setting of the UMG 96RM-E. Recordings can be adjusted
and extended via GridVis.
• The min. recording time base is 1 minute.
• Maximum 4 recordings, each with 100 measured
values, are possible.
Recording 1:
The following measured values are recorded with
the time base of 15 minutes:
• Effective voltage L1
• Effective voltage L2
• Effective voltage L3
• Effective current L1
• Effective current L2
• Effective current L3
• Effective current sum L1..L3
• Effective power L1
• Effective power L2
• Effective power L3
• Effective power sum L1..L3
• Apparent power L1
• Apparent power L2
• Apparent power L3
• Apparent power sum L1..L3
• cos phi(math.) L1
• cos phi(math.) L2
• cos phi(math.) L3
• cos phi(math.) sum L1..L3
• Reactive power fundamental oscillation harmonic L1
• Reactive power fundamental oscillation harmonic L2
• Reactive power fundamental oscillation harmonic L3
• Reactive power fundamental oscillation harmonic
sum L1..L3
The mean value, minimum value and maximum value
are also recorded for each measured value.
Recording 2:
The following measured values are recorded with
the time base of 1 hour:
• Effective energy sum L1..L3
• Inductive reactive energy sum L1..L3
