janitza UMG 96 RM-E - Connection Examples and Guides; Connection Example 1 (RCM)

122
UMG 96RM-E
Connection example 1
(with residual current measurement IPE / IRES)
1)
UL / IEC approved overcurrent
protection system (6A Char. B)
2)
UL / IEC approved overcurrent
protection system
(10A Class CC / Char. C)
3)
Jumpers (external)
4)
Jumpers between connectors
32-33 and 35-36 are only required
from hardware-release 104!
Digital-Eingänge/Ausgänge
UMG 96RM-E (RCM)
V1 V2 V3 VN
Spannungsmessung
3 4 5 6
Strommessung
Versorgungs-
spannung
1 2
RS485
16 17
B
A
B A
28 29 30 31 32 33 34 35 36
Analog-Eingänge
13 14 15
24V
DC
K1 K2
=
-
+
Ethernet
10/100Base-T
PC
K3 K4
K5
=
-
+
=
+
-
37
RJ45
I5 I6
S1 S2 S3
Gruppe 1 Gruppe 2
N/- L/+
S2
S1
S2
S2
S1
S1
L1
L2
L3
Verbraucher
230V/400V 50Hz
N
S2 S1
I4
19 18
S2 S1 S2 S1 S2 S1 S2 S1
IPE
0-30 mA
0-30 mA
IDIFF
2)1) 2) 2)
3) 3) 3)3)
Digital inputs/outputs
Power supply
voltage
Current measurement
Measuring voltage
Analog inputs
Analog inputs
Consumer
Group 1
Group 2
4)4)
