UMG 96RM-E
Measuring process
The UMG 96RM-E measures continuously
and calculates all effective values over a 10/12 period
interval. The UMG 96RM-E measures the real effective
value (TRMS) of the voltage and current connected
to the measurement inputs.
Operating concept
You can program and call up the measured values via
many routes using the UMG 96RM-E.
• Directly on the device via 2 buttons.
• Using the GridVis programming software.
• Through the device's home page.
• Using the Modbus protocol.
You can modify and call up the data using
the Modbus address list. The list can be called
up via the device's home page and can be found
on the enclosed CD.
This manual only describes how to operate
the UMG 96RM-E using the two buttons.
The GridVis programming software has its own online
help system.
GridVis network analysis software
The UMG 96RM-E can be programmed and read out
using the GridVis network analysis software (Download:
www.janitza.com). For this a PC must be connected to
the UMG 96RM-E via a serial interface (RS485) or via
Ethernet.
GridVis features
• Programming the UMG 96RM-E
• Graphical representation of measured values
