Configuration
Connecting the supply voltage
The supply voltage must be connected for
the configuration of the UMG 96RM-E .
The level of the supply voltage for the UMG 96RM-E
is specified on the rating plate.
If no display appears, check whether the operating
voltage lies within the nominal voltage range.
Current and voltage transformers
When the device is delivered, a current transformer ratio
of 5/5A is entered. The voltage transformer ratio must
only be changed if a voltage transformer is connected.
When connecting a voltage transformer, please note
the measurement voltage of UMG 96RM-E given
on the rating plate.
c
Caution!
If the supply voltage does not correspond
to the voltage indicated on the rating
plate, this may lead to malfunctions severe
damage to the device.
C
The adjustable value 0 for the primary
current transformer does not produce any
useful work data, and should not be used.
m
Devices with an automatic frequency
detection require about 5 seconds to
determine the mains frequency.
In the meantime, measured values do not
maintain the guaranteed measurement
uncertainty.
C
Prior to commissioning potential
production dependant contents of the
energy counter, min/max values and
records have to be deleted.
