janitza UMG 96 RM-E - Digital Outputs

78
UMG 96RM-E
Digital outputs
The UMG 96RM-E features two digital outputs in group
1. Three further outputs can be used in group 2.
The User can allocate different functions to the digital
outputs
The functions can be programmed by using the
confi guration menu of the GridVis software.
Fig.: Software GridVis, confi guration menu
Fig.: Digital inputs of group 1 and
digital in- / outputs of group 2
Digital-Eingänge/Ausgänge
28 29 30 3113 14 15
24V
DC
K1 K2
=
-
+
K3 K4
K5
=
-
+
=
+
-
S1 S2 S3
Gruppe 1 Gruppe 2
Digital inputs/outputs
Group 1
Group 2
